6-burner hermetic gas boiling top Super with cast iron grids on gas static fullsize oven and electric grill with 1 grid

713217 - PFXH12SGGE7

Download

Line catalogue
Download all

Product specifications

  • Total power [kW] 52 + 3
  • Frequency [Hz] 50/60
  • Voltage [V] 230 ~
  • Electric power [kW] 3
  • Gas power [kW] 52
  • Natural gas consumption [m³/h] 5,50
  • Oven type Static
  • Vertical distance between trays [cm] 6
  • Guides [n°] 4
  • Cooking chamber dimensions [cm] 92,5x63x40
  • Gas connection diameter 3/4G EN10226-1
  • Width [cm] 120
  • Depth [cm] 70
  • Height [cm] 90
  • Package width [cm] 125,0
  • Package depth [cm] 82,0
  • Package height [cm] 112,0
  • Net weight [kg] 168
  • Gross weight [kg] 188
  • Volume [m³] 01,1500
  • Oven dimensions Full size H. 40 cm
  • Boiling pan support RAAF enamelled cast iron
  • Tray capacity [n°] 4x(883x603)
  • Open burner power [n°- kW] 6x7,5
  • Number of burners [n°] 6
  • Boiling top power [kW] 45
  • Oven power [kW] 7 + 3(grill)
  • Oven temperature range [°C] 150÷290
  • Foot height [mm] 155
  • Foot adjustment [mm] 155/250
  • IPX rating 4"
